3M

3M™ 93-AK 630-1 QS200 Cable Joint, Single-Core, 12/20 kV, 1x 400 - 630 mm²

In stock
SKU: 4054596003590
Regular price €608,01 EUR incl. VAT
Number of conductors 1 Cable insulation outer diameter range (metric) 33.4 - 66.0 mm Shielding type Wire shielding Tape shielding UniShield® Longitudinally corrugated (LC) Insulation outer diameter (metric) 60 mm Cable outer diameter (metric) 74 mm Halogen-free No Shelf life in days 1095 Days Cable type Polymer insulated, copper wire shielded, unarmored cable Smallest sellable unit* Overpack Conductor material Copper Aluminum Maximum conductor size 630 mm² Brand 3M™ With screw connectors No Mining permit No Minimum conductor size 400 mm² Model Cold-shrink Voltage 8.7/15 kV 12/20 kV 12.7/22 kV Voltage rating 12/20 kV Muff type Cold-shrink For connection of paper - with plastic insulated cables No Close Arrow Up Icon

📦 Shipping Information

We ship our products from the Netherlands with care and speed. Shipping method: GLS

🇳🇱 Within the Netherlands
Shipping costs: €6.95
Delivery time: 3–5 business days

🇪🇺 Within Europe (EU)
Shipping costs: €24.95
Delivery time: 3–7 business days

🌍 Outside Europe (worldwide)
Shipping costs: €49.95
Delivery time: 7–14 business days

🔗 You can find more details on our shipping information page .
