The smallest models, the Hyrax 125 and 175, have one eccentric. The models from the Hyrax 250 onwards have two eccentrics, each driven by a hydromotor. The absence of a gear transmission simplifies maintenance.
Features
Safe to use thanks to the Safety Belt safety system.
Suitable for both soil compaction and driving piles and sheet piles.
Higher performance and impact.
Very large amplitude
Easy to maintain and service.
Dutch-made and developed
Oil can be precisely switched off and adjusted with the flow control valve.
Options and accessories
To allow for quick and easy positioning of the vibrating block, both mechanical and hydraulic rotation are possible.
Weight Hyrax + Hydraulic rotation: 258 kg
Weight Hyrax + Hydraulic rotation, ready for operation: 287 kg
Weight Hyrax + Mechanical rotation: 220 kg
Weight Hyrax + Mechanical rotation ready for operation: 249 kg
Accessories can be mounted under the vibrating plate, such as a pole cap in various sizes.
A 350 kN hydraulic sheet pile clamp makes the vibratory hammer suitable for driving steel sheet piles.
